| Type |
Type |
Digital, single-lens reflex, AF/AE camera with built-in flash |
| Recording media |
SD memory card, SDHC memory card*, SDXC memory card* |
| * UHS-I cards compatible. |
| Image sensor size |
Approx. 22.5 x 15.0mm |
| Compatible lenses |
Canon EF lenses (including EF-S lenses) |
| * Excluding EF-M lenses |
| (35mm-equivalent focal length is approx. 1.6 times the lens focal length) |
| Lens mount |
Canon EF mount |
| Image Sensor |
Type |
CMOS sensor |
| Effective pixels |
Approx. 20.20 megapixels |
| Aspect ratio |
3:2 |
| Dust delete feature |
Auto, Manual, Dust Delete Data appending |
| Recording System |
Recording format |
Design rule for Camera File System (DCF) 2.0 |
| Image type |
JPEG, RAW (14-bit Canon original) |
| RAW+JPEG simultaneous recording possible |
| Recorded pixels |
L (Large): Approx. 20.00 megapixels (5472 x 3648) |
| M (Medium): Approx. 8.90 megapixels (3648 x 2432) |
| S1 (Small 1) : Approx. 5.0 megapixels (2736 x 1824) |
| S2 (Small 2): Approx. 2.50 megapixels (1920 x 1280) |
| S3 (Small 3): Approx. 350,000 pixels (720 x 480) |
| RAW: Approx. 20.0 megapixels (5472 x 3648) |
| M-RAW: Approx. 11.0 megapixels (4104 x 2736) |
| S-RAW: Approx. 5.0 megapixels (2736 x 1824) |
| Create/select a folder |
Possible |
| File numbering |
Continuous, Auto reset, Manual reset |
| Image Processing During Shooting |
Picture Style |
Auto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Def. 1 - 3 |
| White balance |
Auto, Preset (Daylight, Shade, Cloudy, Tungsten light, White fluorescent light, Flash), Custom, Color temperature setting (approx. 2500-10000 K), White balance correction, and White balance bracketing possible |
| * Flash color temperature information transmission enabled |
| Noise reduction |
Applicable to long exposures and high ISO speed shots |
| Automatic image brightness correction |
Auto Lighting Optimizer |
| Highlight tone priority |
Provided |
| Lens aberration correction |
Peripheral illumination correction, Chromatic aberration correction |
| Viewfinder |
Type |
Eye-level pentaprism |
| Coverage |
Vertical/Horizontal approx. 98% (with Eye point approx. 22mm) |
| Magnification |
Approx. 0.95x (-1 m--1with 50mm lens at infinity) |
| Eye point |
Approx. 22mm (from eyepiece lens center at -1 m--1) |
| Built-in dioptric adjustment |
Approx. -3.0 - +1.0 m-1 (dpt) |
| Focusing screen |
Fixed |
| Grid display |
Provided |
| Electronic level |
Displayable before and during shooting |
| Mirror |
Quick-return type |
| Depth-of-field preview |
Provided |
| Autofocus |
Type |
TTL secondary image-registration, phase-difference detection with the dedicated AF sensor |
| AF points |
19 (All cross-type focusing*) |
| * Except with certain lenses. |
| Focusing brightness range |
EV -0.5 - 18 (with center AF point, at room temperature, ISO 100) |
| Focus operation |
One-Shot AF, AI Servo AF, AI Focus AF, Manual focusing (MF) |
| AF area selection mode |
Single-point AF (Manual selection), Zone AF (Manual zone selection), 19-point automatic selection AF |
| AI Servo AF characteristics |
Tracking sensitivity, Acceleration/deceleration tracking |
| AF fine adjustment |
AF Microadjustment (All lenses by same amount or Adjust by lens) |
| AF-assist beam |
Small series of flashes fired by built-in flash |
| Exposure Control |
Metering modes |
63-zone TTL full-aperture metering |
| ・Evaluative metering (linked to all AF points) |
| ・Partial metering (approx. 7.7% of viewfinder at center) |
| ・Spot metering (approx. 3.0% of viewfinder at center) |
| ・Center-weighted average metering |
| Metering brightness range |
EV 1 - 20 (at room temperature, ISO 100) |
| Exposure control |
Program AE (Scene Intelligent Auto, Flash Off, Creative Auto, Special scene [Portrait, Landscape, Close-up, Sports, Night Portrait, Handheld Night Scene, HDR Backlight Control], Program), Shutter-priority AE, Aperture-priority AE, Manual exposure, Bulb exposure |
| ISO speed (Recommended exposure index) |
Basic Zone modes*: ISO 100 - ISO 6400 set automatically |
| * Landscape: ISO 100 - ISO 1600 set automatically, Handheld Night Scene: ISO 100 - ISO 12800 set automatically |
| P, Tv, Av, M, B: Auto ISO, ISO 100 - ISO 12800 (in 1/3- or whole-stop increments), or ISO expansion to H (equivalent to ISO 25600) |
| ISO speed settings |
ISO speed range, Auto ISO range, and Auto ISO minimum shutter speed settable |
| Exposure compensation |
Manual: ±5 stops in 1/3- or 1/2-stop increments |
| AEB: ±3 stops in 1/3- or 1/2-stop increments (can be combined with manual exposure compensation) |
| AE lock |
Auto: Applied in One-Shot AF mode with evaluative metering when focus is achieved |
| Manual: By AE lock button |
| HDR Shooting |
Dynamic range adjustment |
Auto, ±1 EV, ±2 EV, ±3 EV |
| Auto image align |
Possible |
| Multiple Exposures |
Number of multiple exposures |
2 to 9 exposures |
| Multiple-exposure control |
Additive, Average |
| Shutter |
Type |
Electronically-controlled, focal-plane shutter |
| Shutter speeds |
1/8000 sec. to 30 sec. (total shutter speed range; available range varies by shooting mode), Bulb, X-sync at 1/250 sec. |
| Drive System |
Drive modes |
Single shooting, High-speed continuous shooting, Lowspeed continuous shooting, Silent single shooting, Silent continuous shooting, 10-sec. self-timer/remote control, 2-sec. self-timer/remote control |
| Continuous shooting speed |
High-speed continuous shooting: Max. approx. 7.0 shots/sec. |
| Low-speed continuous shooting : Max. approx. 3.0 shots/sec. |
| Silent continuous shooting : Max. approx. 3.0 shots/sec. |
| Max. burst |
JPEG Large/Fine: Approx. 40 shots (approx. 65 shots) |
| RAW: Approx. 15 shots (approx. 16 shots) |
| RAW+JPEG Large/Fine: Approx. 8 shots (approx. 8 shots) |
| * Figures are based on Canon’s testing standards (ISO 100 and Standard Picture Style) and an 8 GB card. |
| * Figures in parentheses apply to an UHS-I compatible 8 GB card based on Canon’s testing standards. |
| Flash |
Built-in flash |
Retractable, auto pop-up flash |
| Guide No.: Approx.12/39.4 (ISO 100, in meters/feet) |
| Flash coverage: Approx. 17mm lens angle of view |
| Recycling time approx. 3 sec. |
| External Speedlite |
Compatible with EX-series Speedlites |
| Flash metering |
E-TTL II autoflash |
| Flash exposure compensation |
±3 stops in 1/3- or 1/2-stop increments |
| FE lock |
Provided |
| PC terminal |
None |
| Flash control |
Built-in flash function settings, external Speedlite function settings, external Speedlite Custom Function settings Wireless flash control via optical transmission |
| Live View Shooting |
Aspect ratio |
3:2, 4:3, 16:9, 1:1 |
| Focus methods |
Dual Pixel CMOS AF system/Contrast-detection AF system (Face+Tracking, FlexiZone-Multi, FlexiZone- Single), Phase-difference detection with the dedicated AF sensor (Quick mode), Manual focus (approx. 5x and 10x magnified view possible for focus check) |
| Continuous AF |
Provided |
| Focusing brightness range |
EV 0-18 (at room temperature, ISO 100) |
| Metering modes |
Evaluative metering (315 zones), Partial metering (approx. 10.3% of Live View screen), Spot metering (approx. 2.6% of Live View screen), Center-weighted average metering |
| Metering brightness range |
EV 0 - 20 (at room temperature, ISO 100) |
| Creative filters |
Grainy B/W, Soft focus, Fish-eye effect, Art bold effect, Water painting effect, Toy camera effect, Miniature effect |
| Silent shooting |
Provided (Mode 1 and 2) |
| Touch shutter |
Provided |
| Grid display |
Three types |
| Movie Shooting |
Recording format |
MOV |
| Movie |
MPEG-4 AVC / H.264
Variable (average) bit rate |
| Audio |
Linear PCM |
| Recording size and frame rate |
1920x1080 (Full HD): 30p/25p/24p
1280x720 (HD) : 60p/50p
640x480 (SD) : 30p/25p
* 30p: 29.97 fps, 25p: 25.00 fps, 24p: 23.98 fps, 60p: 59.94 fps, 50p: 50.00 fps |
| Compression method |
ALL-I (I-only), IPB |
| File size |
1920x1080 (30p/25p/24p) / IPB : Approx. 235 MB/min.
1920x1080 (30p/25p/24p) / ALL-I : Approx. 685 MB/min.
1280x720 (60p/50p) / IPB : Approx. 205 MB/min.
1280x720 (60p/50p) / ALL-I : Approx. 610 MB/min.
640x480 (30p/25p) / IPB : Approx. 78 MB/min.
* Card reading/writing speed necessary for movie shooting:
IPB: at least 6 MB per sec./ALL-I: at least 20 MB per sec. |
| Focusing |
Same as focusing with Live View shooting
* Quick mode disabled during movie shooting |
| Digital zoom |
Approx. 3x-10x |
| Metering modes |
Center-weighted average and Evaluative metering with the image sensor
* Automatically set by the focus method. |
| Metering brightness range |
EV 0 - 20 (at room temperature, ISO 100) |
| Exposure control |
Autoexposure shooting (Program AE for movies) and manual exposure |
| Exposure compensation |
±3 stops in 1/3-stop increments (±5 stops for still photos) |
| (Recommended exposure index) |
For autoexposure shooting: 1. ISO 100 - ISO 6400 set automatically. In Creative Zone modes, the upper limit is expandable to H (equivalent to ISO 12800).
For manual exposure shooting: Auto ISO (ISO 100 – ISO 6400 set automatically), ISO 100 - ISO 6400 set manually (1/3- and whole-stop increments), expandable to H (equivalent to ISO 12800) |
| Time code |
Supported |
| Drop frames |
Compatible with 60p/30p |
| Video snapshots |
Settable to 2 sec./4 sec./8 sec. |
| Sound recording |
Built-in stereo microphone, external stereo microphone terminal provided
Sound-recording level adjustable, wind filter provided, attenuator provided |
| Grid display |
Three types |
| Still photo shooting |
Possible |
| LCD Monitor |
Type |
TFT color, liquid-crystal monitor |
| Monitor size and dots |
Wide 7.7 cm (3.0-in) (3:2) with approx. 1.04 million dots |
| Brightness adjustment |
Manual (7 levels) |
| Electronic level |
Provided |
| Interface languages |
25 |
| Touch screen technology |
Capacitive sensing |
| Feature guide / Help |
Displayable |
| Playback |
Image display formats |
Single image display, Single image + Info display (Basic info, shooting info, histogram), 4-image index, 9-image index |
| Highlight alert |
Overexposed highlights blink |
| AF point display |
Possible |
| Grid display |
Three types |
| Zoom magnification |
Approx. 1.5x - 10x |
| Image browsing methods |
Single image, jump by 10 or 100 images, by shooting date, by folder, by movies, by stills, by rating |
| Image rotate |
Possible |
| Rating |
Provided |
| Movie playback |
Enabled (LCD monitor, video/audio OUT, HDMI OUT), built-in speaker |
| Slide show |
All images, by date, by folder, by movies, by stills, by rating |
| Background music |
Selectable for slide shows and movie playback |
| Image protect |
Possible |
| Post-Processing of Images |
In-camera RAW image processing |
Brightness correction, White balance, Picture Style, Auto Lighting Optimizer, High ISO speed noise reduction, JPEG image-recording quality, Color space, Peripheral illumination correction, Distortion correction, Chromatic aberration correction |
| Resize |
Possible |
| Creative filters |
Grainy B/W, Soft focus, Fish-eye effect, Art bold effect, Water painting effect, Toy camera effect, Miniature effect |
| Direct Printing |
Type |
PictBridge (USB and Wireless LAN) |
| Printable images |
JPEG and RAW images |
| Print ordering |
DPOF Version 1.1 compatible |
| Custom Functions |
Custom Functions |
23 |
| My Menu registration |
Possible |
| Custom shooting modes |
Register under Mode Dial C |
| Copyright information |
Entry and inclusion enabled |
| Interface |
Audio/video OUT/Digital terminal |
Analog video (Compatible with NTSC/PAL)/stereo audio output
Computer communication, Direct printing (Hi-Speed USB or equivalent), GPS Receiver GP-E2 connection |
| HDMI mini OUT terminal |
Type C (Auto switching of resolution), CEC-compatible |
| External microphone IN terminal |
3.5 mm diameter stereo mini-jack |
| Remote control terminal |
For Remote Switch RS-60E3 |
| Wireless remote control |
Compatible with Remote Controller RC-6 |
| Eye-Fi card |
Compatible |
| Power |
Battery |
Battery Pack LP-E6 (Quantity 1)
* AC power can be supplied via AC Adapter Kit ACK-E6.
* With Battery Grip BG-E14 attached, size-AA/LR6 batteries can be used. |
| Battery information |
Remaining capacity, Shutter count, Recharge performance, and Battery registration possible |
Number of possible shots
(Based on CIPA testing standards) |
With viewfinder shooting: Approx. 920 shots at room temperature (23°C/73°F), approx. 850 shots at low temperatures (0°C/32°F)
With Live View shooting: Approx. 210 shots at room temperature (23°C/73°F), approx. 200 shots at low temperatures (0°C/32°F) |
| Movie shooting time |
Approx. 1 hr. 20 min. at room temperature (23°C/73°F), approx. 1 hr. 20 min. at low temperatures (0°C/32°F)
* With a fully-charged Battery Pack LP-E6. |
| Dimensions and Weight |
Dimensions (W x H x D) |
Approx. 139.0 x 104.3 x 78.5 mm / 5.5 x 4.1 x 3.1 in. |
| Weight |
Approx. 755 g / 26.7 oz. (CIPA Guidelines), approx. 675 g / 23.8 oz. (Body only) |
| Operation Environment |
Working temperature range |
0°C - 40°C / 32°F - 104°F |
| Working humidity |
85% or less |
Bảo hành: 6 tháng
